Navigating the Wide Selection of Construction Level Laser
With the large selection of construction lasers available these days, it can be a tough job just shopping and deciding on a model to purchase. The task of researching the various models is more than most people want to deal with or have the time to spend.
We will attempt to explain which features do what and which product best fits your needs. Basically speaking, the first thing you should do is figure out what jobs you plan to accomplish with your laser. Do you intend to work only indoors, only outdoors, or both? Do you want to install pipe underground, chair rails in a dining room, fence posts, and construction site grading? These are the questions that will define the features you will want to look for and buy .
What are construction lasers used for you ask?
They are used in a variety of jobs where layout is performed and an accurate, level reference is needed. Jobs such as, installing ceiling tiles, installing chair railings in a dining room, installing receptacles for power within a home under construction. Some tasks are small, such as hanging pictures in a level fashion across a living room wall. Some tasks are large, such as installing sewer pipe or handling a site grading plan for a new building.
Indoor Applications of Laser Levels
Align and plumb your walls
Leveling floors
Attach your laser to a wall or ceiling mount for easy drop ceiling installation
Easily check door or window heights
Installing drop ceilings
Install chair rails and wainscoting in your home
Align shelves, cabinets and trim
Use a tripod for easy installation and alignment of cabinets, chair rails, etc
Outdoor Applications of Laser Levels
Any type of basic surveys
Lasers easily check and level posts and beams on decks, fences and porches
Masonry alignment
Site layout
Easily check land elevations
Construction Level Laser with a slope capability can set grade for proper drainage and irrigation
Align fences, posts and decks
Establishing grades
Contour farming or drainage
When selecting a construction laser, it's not only application-specific, there are basically three types of lasers to make your layout less time consuming for certain distances in construction. They are PLUMB ("Dot LASERS"), LINE LEVEL ("Line Generators"), or ROTARY. For distances from 1' to 150', we recommend PLUMB or LINE GENERATORS. For 200' or greater, we recommend ROTARY. These are basic rules of thumb on model selection and things can always vary depending on your exact task or application.
First, let's discuss the basic models. The following levels emit their lasers in various ways
Plumb or Dot Lasers
These lasers produce single or multiple dots of reference on the wall or work surface. They work much like a reference point, or a laser plumb bob.
Line Level Lasers (Also known as Laser Line Generators)
Another type is one that emits a level line on the wall in a single line or a cross-hair type of fashion. Typically, these types only emit level lines in one direction and onto a single wall or workspace. These are typically used indoors, and are usually small hand-held types of lasers either positioned on a ladder, sawhorse, desk, etc, or mounted to a light-weight jamb-pole or laser platform that extends from floor to ceiling.
Rotary Construction Level Laser
Then, the other type is a rotary laser, which emits a level line in a rotary fashion. Rotary lasers typically emit a level line around the entire room in 360 degrees. Rotary Lasers are usually a little larger and are mounted on sturdy surveying tripods. Some Rotary Laser Levels can be laid over on their side, using an optional trivet that allows them to project on a vertical plane when used in this manner. The rotation of a single laser makes the human eye think it is seeing a line around the room. Hence the name, Rotary Laser. Most Rotary Lasers work well inside, but if you want to work outside, you'll need to make sure you have a laser detector, also known as a laser receiver. This is because the human eye cannot see the laser outside in daylight no more than several feet. More is mentioned below in this article about Laser Detectors.
With the above explanation of how the lasers emit their lines or points, now lets dive into varying types or features of laser levels
Manual-Leveling Lasers
A manual leveling laser requires the operator to manually level the unit by turning the units thumbs screws and getting the unit leveled by looking at the bubble vials.
Self-Leveling and Construction Level Laser
A self-leveling laser automatically finds and maintains a level within a specified range. Some lasers have a bubble vial and you perform rough leveling and then the laser itself will take over and do the fine leveling. Or, some you get the laser set up and somewhat close to being level, and then the laser will level itself. And, many self or auto-leveling laser levels will continue to level itself if the setup or platform becomes jarred accidentally. And, many times they will shut themselves off if they get out of level by say 3% or 5% in an attempt to stop you from using the beam as a reference. Also, you should note that some lasers advertise themselves to be Automatic-Leveling.
Please be aware that the terms self-leveling and automatic-leveling can mean different things. The terms "self leveling" and "automatic leveling" tend to conflict one another if you're new to laser terminology. Most Self-Leveling Lasers have an internal Pendulum that does the leveling. And some that are called Automatic-Leveling Lasers have electronic servo motors that do all of the leveling for you. We recommend taking the time to read, ask, and learn the differences once you have narrowed down a few lasers when making your decision.
Horizontal Lasers
A horizontal beam laser will only emit a single beam from its beacon.
Dual-Beam Lasers: (also known as Split-Beam Lasers)
These types of laser levels emit horizontal or vertical beams to establish both level and plumb reference lines. Please note that the term of Dual-Beam really just means that the laser is able to produce its regular plane and produce a reference point such as a plumb-up dot on the ceiling. Don't assume that the laser you want will produce a horizontal and vertical "plane" at the same time. Usually when a laser is described as "Dual-Beam", it usually means one level beam like with a Rotary Laser producing a flat line around the room, and the other beam is simply a plumb-up "dot" on the ceiling.
We are unaware of any Construction Level Laser that will produce both horizontal and vertical level loops around the room at the same time. Most Rotary Lasers are either horizontal or vertical, (one or the other, not both). Dual-Beam is just another beam, not necessarily another "plane", as the second beam could be a simple "dot" reference point.
Laser Detectors (Laser Receivers)
Also, an integral part of using Construction Level Laser is a laser detector. Laser detectors are also known as laser receivers. Laser Detectors typically mount to level rods and work to detect the laser beam when you're working outside. Most always, a laser detector is required if you're working outside with a laser level since a laser line is difficult to see during the daytime hours. Most detectors produce sound, a short beep when you're close to being on level, and then a steady, solid beep tone when you're at level.
Laser Detectors can shorten the amount of time needed when trying to find the level beam and get on level. Most Detectors have a visual and audible alarm. The visual is usually an LCD screen and the audible is a beeping noise that beeps faster and faster the closer you get to being on level. When you do get on level, a solid tone that alerts when you're on level. Most detectors will give you a fast tone if you need to move the detector down, a slower tone if you need to move up, and a steady tone when you are on grade.
Fixed versus Variable Rotation Speeds of Rotary Lasers.
Construction Level Laser come with either a Fixed Rotation Speed or a Variable Rotation Speed. RPM (Rotations Per Minute) represents the number of times the laser in a Rotary Laser rotates in one minute. Most Construction Rotary Lasers have either a fixed RPM or a variable RPM. A faster RPM is dimmer but travels farther (so you get more range). A slower RPM does not travel as far but is brighter and easier to see. Use a slower RPM when inside because the beam will be easier to see and a faster RPM when outside because it will travel farther.
Optimizing Construction Level Laser
When doing exterior work (outside jobs such as grading, setting culverts, concrete driveways) you need one speed, and that speed is fast. The line from Construction Level Laser is not visible to the human eye outdoors in bright sunlight, so you will need to use a laser detector to find the exact location of the laser line. The faster the rotation, the harder it is for a human eye to see it, but the laser detectors work better with faster rotations. For a Rotary Laser Detector (Also known as a "Receiver") to locate the line the RPM must be at least 600.
Rotary Laser Levels with variable speeds work well for interior work. A variable RPM allows the user to adjust the laser to the speed of best visibility. Slower rotations have a more visible beam. Faster rotations resemble a chalk line. You’ll want to set the rotation slow enough to where it is just fast enough to be considered a solid line on the wall, as this allows for the best mix of solid and brightness. If you need a solid dot reference set the laser at 0 RPM.
